Hantek Hantek2000 Series User Manual

Mechanical
Dimension
199 x 98x 40mm (L x W x H)
Weight
624g
Arbitrary Waveform Generator （Hantek2D72/Hantek2D42）
Waveform Frequency
Sine: 1Hz~25MHz
Square: 1Hz~10MHz
Ramp: 1Hz~1MHz
EXP: 1Hz~5MHz
Sampling
250MSa/s
Amplitude
2.5Vpp(50Ω)
5Vpp(High impedance)
Frequency Resolution
0.10%
Channel
1CH waveform output
Waveform Depth
512Sa
Vertical Resolution
12 bit
Output Impedance
50 Ω
Square Characteristics
Pulse width accuracy
±10ns
DMM
Maximum Resolution
4000 Counts
DMM Testing Modes
Voltage, Current, Resistance, Capacitance, Diode &
On-Off
Maximum Input Voltage
AC : 600V DC : 600V
Maximum Input Current
AC : 10A DC : 10A
Range
Accuracy
Resolution
DC Voltage
400.00mV
±（0.8% + 5）
100uV
4.000V
1mV
40.00V
10mV
400.0V
100mV
600.0V
±（1% + 2）
1V
Overload protection:
