Harman Kardon AVR 745

Ref. Designator Part Number
Description
DSP PCB ASS'Y
Y112 H03-OSXNL4515B0-R CRYSTAL 45.1584MHz 22p SO22320D5-45.1584-T&R USA ONLY
N111 H03-SOUSB45810B-R JACK R41-5810B (Mitsumi) XM/DT connector USA ONLY
N101 H03-SOUSB5005K0-R AU6-EC-005K0
L414 L415 RS3AD0270NA-R RES,CHIP 27 OHM 1/16W +/-5% 0603
L413 R421 RS3AD0751NA-R RES.CHIP,750OHM,1/16W,+-5%,0603.
L401 L403 L405 L902 H03-FB05B3580NN-R BEAD AXIAL/TAP,HC3580 80.5ohm
L431 L432 L434 L702 H03-LAINB0470CR-R LF 47U0H +10% 5.8 OHM 500MI0A
L421 L426 L428 L429 L430
L501
H03-LAINB047ACR-R LF 4U7H +10% 1.7 OHM 190.0A
P091 H03-ICLM19CIZIE-R IC TEMPERATURE SENSOR LM19CIZ 2.4V TO-92
Y105 H03-OSCEM05M0RU-R CERAMIC RESONATORCSTLS_G 5.0MHz
Y413 H03-OSCEM24M5RU-R VCXO 24M576 HZ +50 PPM -50 PPM 0 OHM 3.3V
Y111 H03-OSX06M0HZ00-R CRYSTAL6MHz 2P WOOIN HC-49/S_22PF
K700 H03-RLL0516632B-R RELAY PWR 5.0V 166.0OHM 1.0A 24.0V
N802 H03-SORA40RSAGN-R JACK RCA 4P JB040131ZG GN BN PP TA ,GOLD COLOR
N801 H03-SORA40RSCGN-R JACK RCA 4P JB040131QG WH BU RD GY,GOLD COLOR
J411 J413 J414 H03-SORX22073GN-R JACK RCA+ OPTICAL RX YKC22-0733N,GOLD COLOR
J402 H03-SOTX22073GN-R JACK RCA+ OPTICAL TX YKC22-0732N,GOLD COLOR
N931 H03-WE03B012000-R WIRE ASS`Y UL1007#26 120MM 2.0MM 3P WHT
N119 H03-WN03SB00000-R CONNECT 2.0mm 3P GIL-S-3P-S2T2-EF
P711 P712 H03-WN03SE00000-R CON 3.96MM PITCH MOLEX 35313-0310
N707 H03-WN04AB100WH-R CONN WAFER 2.0MM 4P 35237-0410 WHT
P704 H03-WN05SB00000-R CONNECT 2.0mm 5P GIL-S-5P-S2T2-EF
N716 H03-WN07AB100WH-R CONN WAFER 2.0MM 7P 35237-0710 WHT
P715 H03-WN07SB100WH-R CONN WAFER 2.0MM 7P 35336-0710 WHT
N714 H03-WN09AB100WH-R CONNECT WAFER 2.0mm 9P 35237-0910 WHT
P703 H03-WN09SB00000-R CONNECT 2.0mm 9P GIL-S-9P-S2T2-EF
P713 H03-WN09SB100WH-R CONNECT WAFER 2.0mm 9P 35336-0910 WHT
N706 H03-WN15AB100WH-R CONNECT WAFER 2.0mm 15P 35237-1510 WHT
N705 H03-WN16AB100WH-R CONNECT WAFER 2.0mm 16P 35237-1610 WHT
P714 H03-WN16DI00000-R GF120-16S-TS 1.25mm 16P
N702 N710 H03-WN19AB00000-R CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910 0 0
P701 H03-WN22DI00000-R GF120-22S-TS 1.25mm 22P
P708 H03-WN29DI00000-R CONNECT 1.25MM 29PINGF120-29S-TS
BK10 H03-ZMD27S09A00-R BRACKET BKT XM
FRONT PCB ASS'Y
Capacitors
C127 CEHFC0107NN-R CE 100U0F +20% 16.0V 85C
C119 C128 C551 CCZID0104NA-R CC 100N0F +80% -20% 50.0V F
C517 H03-CEHEC02275E-R CE 220UF +20% 10.0V D6.3XL11 P5MM 85C SK 220/10V 5 X11
C718 H03-CEHFC04765E-R CE47UF +20% 16.0V D5XL11 P5MM 85C SK 47/16V 5 X11
C501 C502 C708 H03-CEHFC04762S-R CE 47UF +20% 16V D5XL7 P2.5MM 2000hours 85C
C503 C504 H03-CEHFC01062S-R CE 10UF +20% 16V D4XL7 P2.5MM 2000hours 85C
C125 C126 H03-CFHKA0473NN-R CAP POLYESTER METAL 47NF 100V 20% CPM
C701 C704 C706 CZDII0100CE-R CAP CERAMIC/CHIP 10PF 50V CH D N 0805
C120 C121 C122 C400 C401
C403 C404 C717 C725 C726
C727 C900
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C702 CZJII0101CE-R CAP CERAMIC/CHIP 100PF 50V CH J NPO 0805
C703 C705 CZJII0122CC-R CAPCHIP 1n2F 50V SL J X7R 0805 +/-5%
C300 C301 CZJII0821CE-R CAP CHIP 820pF 50V SL J NP0 0805
C506 CZKII0221BA-R CAP CHIP 220PF 50V K SL 0603
C252 C253 CZKII0222BC-R CAP CHIP 2N2F +10% -10% 50.0V X7R 0603
C201 C211 CZKII0223BC-R CAP CHIP 22N0F +10% -10% 50.0V X7R 0603
C1 C2 C124 C251 C254 C405
C406 C407 C411 C521 C552
C553 C709 C723
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
Semiconductors
Q821 H03-TRMPSA06NNA-R TR-SLPLF MPSA06 N 500MI0A TO-92 NPN
Q823 H03-TRMPSA56YNA-R TR-SLPLF MPSA56 Y PNP -500MI0A -300V
D301 H03-DG1N04148NB-R D-SLP 1N4148 100.0V 150E-3A
AVR745
harman/kardon
109
