Ref. Designator Part Number
Description
FRONT PCB ASS'Y
N214 H03-WN19AB00000-R CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910 0 0
P216 H03-WN19SB00000-R CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0
N205 H03-WN22AI00000-R GF120-22S-LS 1.25mm 22P
N204 H03-WS4261005FN-R WIRE ASS'Y UL2547/1007#26 100MM 4P 2.0MM WHT
N202 H03-WS4265913FN-R CNT ASSY 2.0MM 4P 590MM SHIELD 26AWG UL2547 1/3
N210 H03-WS5264823FN-R UL1533/2547#26 STR 480mm 2.0mm 5P WHT
N212 H03-WS5248505CW-R WIRE ASS'Y UL1007/1533#24(TA)850mm 2.0mm 5P WHT
N208 H03-WS6265105EN-R WIRECONASY DL 2.0MM 6P 510MM UL1533 SHIELD 26 1
N211 H03-WS7260805EN-R WIRE ASS'Y UL1533/1007#26 80MM 2.0MM 7P WHT SHILED
FL1 H03-XD18BT19GNA-R 18-BT-19GINK
S1 S2 S3 S4 S5 S6 S7 S8 S9 H03-ZMB01S02200-R SPRING PLATE GND C5212 0.2T
J41 H03-ZMC12S17A00-R AC PUN SHIELD DIGITAL ET
J42 H03-ZMD12S01A00-R SHIELD IR
J43 H03-ZMD12S01B00-R SHIELD MICROPHONE
S201~S220 H03-SWC2A112FS1-R SWI TACT VERTICAL SKQNADD010
L251 H03-LAINB0470CR-R LF 47U0H +10% 5.8 OHM 500MI0A
L120 H03-LAINB047ACR-R LF 4U7H +10% 1.7 OHM 190.0A
RM72 H03-DPLP200LNNN-R PIN PHOTO DIODE LP-200TL
NJ71 H03-SO3P5179NNN-R JACK PHONE 3.5PI PJ0435179N
NJ70 H03-SORA1JE01NN-R JACK RCA 1P JE010003MN GND OR
NJ11 H03-SORA3313PNN-R CON PHONO SCKT RCA-313P 3 PINS
NJ12 H03-SORA8OSC5N8-R JACK S-VIDEO 1P C40160261N
NJ10 H03-SOSS9CKX3NN-R JACK PHONE 6.35 H70980110S 9P BK
NJ79 H03-SOTORX177LT-R FIBER OPTIC RECEIVING TORX177L (F, T)
MAIN PCB ASS'Y
Capacitors
C101 C102 C103 C104 C107
C108 C109 C110 C111 C112
C113 C114 C115 C116 C117
C118 C205
CCKID0101NA-R CC 100P0F +10% -10% 50.0V Y5P
C307 C308 C313 C314 C403
C404 C569 C570
CCKID0271NN-R CC 270P0F +10% -10% 50.0V 2B4
C433 CCMFD0103NN-R CC 10N0F +20% -20% 16.0V Y5S
C119 C120 C203 C212 C214
C527 C531 C709 C711 C712
C713
CCZID0104NA-R CC 100N0F +80% -20% 50.0V F
C315 C316 C409 C410 CCCIC0030NN-R CAP CERAMIC 3PF 50V C CH TAP
C317 C318 C411 C412 CCKIC0181NA-R CC 180P0F +10% -10% 50.0V Y5P
C329 C330 C425 C426 CCKIC0222NA-R CC 2N2F +10% -10% 50.0V Y5P
C707 CCZGC0104NA-R CAP CERAMIC 100NF 25V Z Z5U TAP
C331 C332 C407 C408 H03-CEHEC02275E-R CE 220UF +20% 10.0V D6.3XL11 P5MM 85C SK 220/10V 5 X11
C206 C208 C213 C309 C310
C405 C406 C526 C710
H03-CEHGC01075E-R CE 100U0F +20% 25.0V 6.3X11 85C P5MM SK 100/25V 6.3 X11
C210 H03-CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C SK 1/50V 5 X11
C301 C302 C401 C402 C518
C519 C521 C530 C708 C429
H03-CEHIC01065E-R CE 10U0F +20% 50.0V 85C P5MM 5X11 SK 10/50V 5 X11
C207 H03-CEHIC04755E-R CE 4U7F +20% 50.0V 85C P5MM SK 4.7/50V 5 X11
C303 C304 C305 C306 C421
C422 C423 C424
H03-CEHJA0477MN-R CE 470U0F +20% 63.0V 85C SK 470/63V 13 X21
C706 CEMFA0478BK-R CAP ELEC 4700UF 16V M 16X25 85C 120HZ ELITE
C432 H03-CEMGC04775E-R CE 470U0F +/-20% 25.0V 10X13 85C SK 470/25V 10 X13
C323 C324 C430 C431 CFLJC0683NN-R CPM 68N0F +5% 63.0V
C506 C507 C508 C516 C528
C529 C701 C702 C703
CPIKC0473NN-R CPF 47N0F +10% 100.0V
C211 C319 C320 C321 C322
C413 C414 C415 C416
H03-CEMKC0106AH-R CAP ELEC 10UF 100V M 6.3X11 SHL
C325 C326 C327 C328 C417
C418 C419 C420
H03-CPJJC0104NN-R CAP POLYESTER NON METAL 0.1uF 63V J TAP PCMT365 76104
C571 C572 H03-CEMJA0159KA-R CAP ELEC 15000uF 63V M 35x50 LSW153M1JQ50M
C573 H03-CEMDC0478KA-R CAP ELECTROYTIC 4700UF 6.3V M 12.5X21 (SKP472M0JI21R)I
C333 C335 C336 C434 CCKIC0103NA-R CC 10N0F +10% -10% 50.0V Y5P
C509 C510 H03-CEHHC0228MN-R CE 2200UF +20% 35.0V 85C 16X25
AVR745
harman/kardon
