Ref. Designator Part Number
Description
MAIN PCB ASS'Y
C517 H03-CEHIA0228MN-R CE 2200UF +20% 50.0V 85C 16X35
C705 H03-CEMFA0688BK-R CAP ELEC 6800UF 16V M 16X25 85C 120HZ SK 6800/16V 16 X25
C105 C106 CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
Semiconductors
D205 D206 D301 D302 D303
D304 D305 D306 D307 D308
D401 D402 D403 D404 D405
D406 D407 D408 D409 D410
D411 D412 D603
H03-DG1N04148NB-R D-SLP 1N4148 100.0V 150E-3A
D101 D102 D103 D104 D508
D509 D703
H03-DR1N04004NA-R D-SR 1N4004 400.0V 1.0A
D204 H03-DZGE12V10MA-R MZ0.5GE12V-10 12V 10mA
D207 H03-DZGE3V320MA-R DIODE ZENER MZ0.5GE3V3-20 3.3V 20mA
Q309 Q310 Q411 Q412 H03-TR2SA1145YF-R TRANSISTOR PNP 2SA1145-Y(F) TO-92 HFE:120~240
Q443 H03-TRKRC107MNA-R TR-SLPSWA KRC107M NPN
Q315 Q316 Q319 Q320 Q417
Q418 Q421 Q422 Q442
H03-TRKTA1024NA-R TR-SLPLF KTA1024 Y PNP 50MI0A -150V
Q311 Q312 Q410 Q413 Q414 H03-TRKTA1268NA-R TR-SHPLF KTA1268BL PNP 100MI0A 120V
Q307 Q308 Q407 Q408 Q426
Q441
H03-TRKTC3198NA-R TR-SLPLF KTC3198BL NPN 150MI0A
Q301 Q302 Q303 Q304 Q305
Q306 Q313 Q314 Q337 Q338
Q401 Q402 Q403 Q404 Q405
Q406 Q409 Q415 Q416 Q425
H03-TRKTC3200NA-R TR-SHPLF KTC3200BL NPN 100MI0A 120V
Q317 Q318 Q321 Q322 Q419
Q420 Q423 Q424
H03-TRKTC3206NA-R TR-SLPLF KTC3206 Y NPN 50MI0A 150V
Q601 H03-TRKTD1302NA-R TR-SLPLF KTD1302 B NPN 300MI0A 20V
D502 D505 H03-DU2W04MMF00-R DIODE 2W04M-MF RC-2 Kink Type
D701 H03-DUKBU6GMF6N-R KBU6G-MF RS-6 Kink Type
IC73 H03-ICKIA278R06-R 4 TERMINAL 2A OUTPUT LOW DROP
VOLTAGE REGULATOR KIA278R06PI TO-220IS-4 +6V
IC71 H03-ICKIA278R33-R 4 TERMINAL 2A OUTPUT LOW DROP
VOLTAGE REGULATOR KIA278R33PI TO-220IS-4 +3.3V
IC72 H03-ICKIA7805I2-R IC-REGPOSFXD KIA7805API NORMAL TO-220IS +5V
IC59 H03-ICKIA7812I2-R IC-REGPOSFXD KIA7812API NORMAL +12V
IC54 H03-ICKIA7824I2-R IC-REGPOSFXD KIA7824API TO-220IS NORMAL +24V
IC51 IC60 H03-ICLM07815BD-R IC-REGPOSFXD KIA7815API NORMAL +15V
IC52 H03-ICLM07915BD-R IC-REGNEGFXD KIA7915API NORMAL TO-220AB -15V
Q329 Q330 Q433 Q434 H03-TR2SA1859BC-R TR-SHPLF 2SA1859A PNP -2.0A
Q335 Q336 Q439 Q440 H03-TR2SA1986AC-R TRANSISTOR PNP 2SA1986-R(AC,F) HFE:55~110 ADD MICA SHEET SIZ
Q331 Q332 Q435 Q436 H03-TR2SC4883BC-R TR-SHPLF 2SC4883A NPN 2.0A
Q333 Q334 Q437 Q438 H03-TR2SC5358AC-R TRANSISTOR NPN 2SC5358-R(AC,F) HFE:55~110 ADD MICA SHEET SIZ
Q327 Q328 Q431 Q432 H03-TRKTA1360BE-R TRANSISTOR PNP KTA1360 TO-126
Q701 Q702 Q703 Q704 H03-TRKTC3114NE-R TRANSISTOR NPN KTC3114 TO-126
Q323 Q324 Q429 Q430 H03-TRKTC3423BE-R TRANSISTOR NPN KTC3423 TO-126
D210 H03-DS05GBUSCNB-R DIODE PG05GBUSC
IC22 H03-ICLM02068D2-R IC-OPERAMP NJM2068M-TE1 DUAL SOP8
Resistors
R351 R352 R367 R368 R445
R446 R447 R448
H03-RM3EG0100LN-R RMF 10R0 OHM +5% 500MI0W
R303 R304 R388 R389 R473
R474 R477 R478
RC3DI0100IN-R RCF 10R0 OHM +5% 250MI0W
R213 R221 R353 R354 R369
R370 R457 R458 R459 R460
R717
RC3DI0101IN-R RCF 100R0 OHM +5% 250MI0W
R211 R508 R601 RC3DI0102IN-R RCF 1K0 OHM +5% 250MI0W
R485 R706 R714 RC3DI0103IN-R RCF 10K0 OHM +5% 250MI0W
R207 R214 R216 R217 R218
R219 R220 R309 R310 R479
R480 R602
RC3DI0104IN-R RCF 100K0 OHM +5% 250MI0W
R363 R364 R365 R366 R461
R462 R463 R464
RC3DI0150IN-R RCF 15R0 OHM +5% 250MI0W
