64 H03-SORA10003GN JACK RCA 1P JE010003SG GND YELLOW 1
65 SOPA96063NN JACK D-SUB 9P 87204-6063 W/DUST COVER BK 1
66 H03-SOJW2350SNN JACK PHONE 3.5 EP-1401A 6 OR 5
67 H03-ZMC12S16A00 BKT GROUND 1
68 H03-ZMC11S10A00 BKT FAN REAR 1
69 H03-SOYKF457009 JACKI HDMI YKF45-7009 3
70 H03-SOR12BJ12GN JACK RCA 12P BJ120154JG R4 BU4 G4 1
71 H03-SORA60031GN JACK RCA+S-VIDEO 6P C80300312G 2
72 H03-ZMD27S02A00 PANEL REAR AVR745US 1
73 H03-SOUSB45810B JACK R41-5810B (Mitsumi) XM/DT connector 1
74 H03-SOUSB5005K0 JACK USB 5P AU6-EC-005K0 1
75 H03-SOTX22073GN JACK RCA+ OPTICAL TX YKC22-0732N 1
76 H03-SORX22073GN JACK RCA+ OPTICAL RX YKC22-0733N 3
77 H03-SORA40RSAGN JACK RCA 4P JB040131ZG GN BN PP TA 2
78 H03-SORA40RSCGN JACK RCA 4P JB040131QG WH BU RD GY 2
79 H03-ZMD27S05A00 BKT IPOD 1
80 H03-SO1R018H91E JACK IPOD DA1R018H91E 1
81 H03-SORA1J440GE JACK RCA 1P PPJ-440FEG PP 1
82 H03-SORA64105GN JACK RCA 6P JB060132PG WWWRRR 3
83 H03-ZVC11TUNE01 TUNER MODULE KST-MB011MW0-81 US 1
84 H03-ZMC11S04B00 BKT FRAME-GUIDE 1
85 ZMC12S13AYE STANDOFF HEX M4x0.7 6x31.9H 2
86 SO0A18P8CN
N
JACK MODULAR GDL1-8P8C 8T B
K
1
87 H03-SOPA81M367G JACK SPEAKER 8P GOLD METAL SH081M367G GY BU RD WH 1
89 H03-ZMD27HS0400 HEATSINK REG. TR 68X20X50 1
90 ZFNR13830SB RUBER SIDE 50x22x3 6
91 H03-ZMC12S07A00 COVER BOTTOM 1
92 ZUC1201AABK SPONGE 30X30X10T BK 3
93 H03-ZMD2701ZANI BKT POSISTOR 1
94 H03-ZMD12S01C00 SHIELD DSP AVR745 1
95 --- BKT HDMI C3 1
96 --- KNOB CORK 14
97 H03-ZMD27S07A00 SHIELD AL 1
98 H03-ZUD0301AABK SPONGE UL 30X30X12T 1
99 BKT XM 1
SW H03-SWC2A112FS1 SWITCH TACT SKQNADD010 12V 50mA 20
N1 ZNSSM4045HZ NUT M4 HEXAGON CIRCULAR EXTERNAL 4
N2 ZNSSM3023HZ NUT M3 ZN PLATED 1
S1 ZSTBM3010BB SCREW ST BH 3X10 64
S2 ZSTWM3008BY SCREW ST WPH 3X8 49
S3 ZSMCM4010BB SCREW BM 4X10 4
S4 ZSTWM4008BC SCREW ST WPH 4X8 SILVER CHROM 12
S5 ZSTWM3006BB SCREW ST WPH 3X6 7
S7 ZSTBM3012BY SCREW ST BH 3X12 PIVOT 36
S8 ZSMCM4008BY SCREW BM 4X8 3
S9 ZSMBM3014BZ SCREW M.S M3X14 ZN PLATED 1
S10 ZSMPM3006LB SCREW BM 3X10 B 3
S11 ZSTBM3008BY SCREW ST BH 3X8 1
S12 ZSTBM3014BY SCREW ST BH 3X14 PIVOT 2
SG ZSTGM3010BB SCREW ST BH 3X10 GROUND 46
W1 ZWM623108SZ WASHER SPRING 3 39
W2 ZWM803305PZ WASHER PLAIN 3 20
W3 ZWM763109SZ WASHER SPRING 4 4
W4 ZWMC04810PZ WASHER PLAIN 4 4
AVR745
harman/kardon
33
