PIN PIN NAME RECEVIER NAME IN/OUT FUNCTION
76 PDL5/AD5/FLMD1 JTAG IN Debug port
77 PDL6/AD6 Video I2C DATA-HDMI-SDA IN/OUT farodja,HDMI i2c
78 PDL7/AD7 Video I2C CLK-HDMI-SCK OUT farodja,HDMI i2c
79 PDL8/AD8 backup eeprom/HDMI eeprom1 I2C data IN/OUT EEPROM DATA
80 PDL9/AD9 backup eeprom/HDMI eeprom1 I2C clk OUT EEPROM CLK
81 PDL10/AD10
HDMI eeprom0 I2C data
IN/OUT EEPROM DATA
82 PDL11/AD11
HDMI eeprom0 I2C clkl
OUT EEPROM CLK
83 PDL12/AD12 FLDM0,1 CONTROL OUT Flash programming mode
84 PDL13/AD13 CODEC_INT IN AK4114 INT0
85 PDL14/AD14 CODEC_SDA IN/OUT AK4114 SDA
86 PDL15/AD15 CODEC_SCL IN/OUT AK4114 SCL/CS4391A M2
87 PDH0/A16 CODEC_RESET OUT AK4114 PDN
88 PDH1/A17 AD1852 CE IN DAC CE
89 P711/ANI11 DSP_SDA
IN/OUT
DSP I2C DATA
90 P710/ANI10 DSP_SCL OUT DSP I2C CLOCK
91 P79/ANI9 DAC IN IN CS4391A M1
92 P78/ANI8 DSP_RESET OUT DA610 RESET
93 P77/ANI7 AD1852 DATA OUT DAC DATA
94 P76/ANI6 AD1852 CLK OUT DAC CLK
95 P75/ANI5 4051_IN IN 4051_IN
96 P74/ANI4 4051_A OUT 4051_A
97 P73/ANI3 4051_B OUT 4051_B
98 P72/ANI2 4051_C OUT 4051_C
99 P71/ANI1 Audio ic ce2 OUT TC9162_CE
100 P70/ANI0 4094 ce OUT 4094 CHIP ENABLE
