Inside Lifts - Installation & Owner’s Manual TEC0091 2016JUN30 P/N: 630-00076-Rev A |
| www.harmar.com | 800-833-0478
© 2016 Harmar All Rights Reserved
21
INSTALLER
Plug in lifting motor.
AL-425
AL-215
AL-225
AL-435 Series
Attach lifting arm as shown to the right
according to lift model.
Figure 21-1
Figure 21-2
INSTALLATION
4. Attach lifting arm as shown according to lift
model. [Figure 21-1]
5. Plug in lifting motor. [Figure 21-2]
To Next Page
