ASSEMBLYPARTS
ASSEMBLY PA RTS
ITEM
ITEM
QTY
QTY
PART NO.
PART NO.
DESCRIPTION
DESCRIPTION
11 201-ZB03-C MOTOR HOUSING
21 210-ZB03-C MOTOR HOUSING COVER
31 220-ZB03-C OUTER POSTTUBE
41 400-3B01-A FLANGEBUSHING
51 401-3B01-A CUPBUSHING
61 529-ZB03-C MOTOR HOUSING-GEARPLATE
72 530-ZB03-C LIMITRING
81 700-1D02-A MOTOR, ANKARSRUM, KSV4030-822
91 ALA21094 STICKER,"CAUTION"
10 1 ALA21411 FLANGEBUSHING BRZ3/8X1/2X1/2
11 4 BHCS-0_25-20--0_50-SS BUTTON HEAD, 1/4-20 X0.50, SS
12 4 BHCS-10-24--0_50-NP-SS BUTTON HEAD, 10-24 X0.50W/NYLON PATCH, SS
13 3 BHCS-M6-1_00-16-SSBUTTON HEAD,M6-1X16MM, SS
14 1 H425231 MOTOR HOUSING GEARPIN -A
15 1 H425232 MOTOR HOUSING GEAR PIN -B
16 1H425240 DOUBLESPROCKET19-35,8-35
17 1H425241 DOUBLESPROCKET19-35 ,8-40
18 1H425255 LIMIT/MOTOR HOUSINGSPACER
19 1H425262 BUSHING 1/2ID,5/8OD,5/8L
20 1H425263 BUSHING 3/8ID,5/8OD,1/2L
21 1H425264 BUSHING 1/2ID,1"OD,1/2L
22 2H425900 CHAIN, 35 PITCH -26 LINKS
23 1H425901 CHAIN, 40 PITCH -33 LINKS
24 2PHMS-2-56--1_00-SSPAN HEAD, #2-56X1.00,SS
25 1RHSS-0_25-20--0_25-NROUND HEAD,1/4-20 x.25"NYLON
26 1 RR-0_37-EC-Z E-CLIP 3/8SHAFT,Z
27 1 RR-0_50-EC-Z E-CLIP 1/2SHAFT,Z
28 2 SSCP-8-32--0_50-SS SETSCREW,8-32X0.50,SS
29 3WASH-0_25-0_50--0_06-SL-Z1/4"SPLIT LOCK WASHER
30 2WASH-0_37-0_62-0_06-RH-SSWASHER, 3/8"IDx5/8"ODx0.06" THICK, 18-8SS
31 3WASH-0_50--0_88-ZWASHER, 1/2"IDx7/8"ODx0.075"THICK,ZP
AL225, AL425 & AL
SERIES BASE
EXPLODED VIEWS
