Maximum 6800+ Frame Power Ratings
Table 2-1 describes the maximum allowable power ratings for 6800+
frames.Note the given maximums before installing any 6800+ modules
in your frame.
VCA/VDA/VEA6800+ modules can be installed in FR6802+ frames
and 6000/7000 series frames.
Table 2-1. Maximum Power Ratings for 6800+ Frames
6800+ Frame Type
Max. Frame
Power
Dissipation
Number of
Usable Slots
Max. Power
Dissipation Per
Slot
FR6802+XF
(frame with AC power
supply)
120 W 20 6 W
FR6802+XF48
(frame with DC power
supply)
105 W 20 5.25 W
