Chapter 3: Specifications
Outputs
Table 3-4. VCA6800+ Output Specifications
Item Specification
Number of outputs 4 or 8
Output impedance 75Ω
Output return loss > 45 dB to 5 MHz
> 40 dB to 10 MHz
Output isolation > 40 dB @ 10 MHz
Response variation < 0.1 dB @ 10 MHz
Phase match ± 0.2°
Table 3-5. VDA6800+ Output Specifications
Item Specification
Number of outputs 4 or 8
Output impedance 75Ω
Output return loss > 45 dB to 5 MHz
> 40 dB to 10 MHz
Output isolation > 40 dB @ 10 MHz
Response variation < 0.1 dB @ 10 MHz
Phase match ± 0.2°
Table 3-6. VEA6800+ Output Specifications
Item Specification
Number of outputs 4 or 8
Output impedance 75Ω
Output return loss > 45 dB to 5 MHz
> 40 dB to 10 MHz
Output isolation > 40 dB @ 10 MHz
Response variation < 0.1 dB @ 10 MHz
Phase match ± 0.2°
