VCA / VDA / VEA6800+ Installation and Operation Manual 31
Chapter 3: Specifications
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Table 3-9. VEA6800+ Performance Specifications
Item Specification
Gain range – 3 dB to + 3 dB
Frequency response < ± 0.05 dB DC–10 MHz
< ± 0.2 dB to 20 MHz
–3 dB > 50 MHz
Line tilt < 0.20% DC coupling
Field tilt < 0.20% DC coupling
Differential gain < 0.15%
Differential phase < 0.15°
DC offset < 25 mV
Max. cable length of EQ 0–300 m Belden 8281 cable
Max. cable length for optional EQ 0–200 m Belden 8241 cable
0–250 m Belden 1505A cable
0–300 m Belden 1694A cable
0–200 m PSF 1/3 cable
0–250 m Nokia 0.6/2.8 cable
0–250 m VPM2000 cable
EQ response < ± 0.05 dB to 5 MHz
< ± 0.15 dB to 10 MHz
S/N ratio > 70 dB by VM700
Power dissipation < 2 W
