Module Descriptions
Front Module
VCA6800+
Figure 1-1 is a generic top-front view of a typical VCA6800+ front
module. See Figure 2-1 on page 17 for jumper and adjustment
locations.
Figure 1-1. Typical VCA6800+ Front Module
VDA6800+
Figure 1-2 is a generic top-front view of a typical VDA6800+ front
module. See Figure 2-6 on page 20 for jumper and adjustment
locations.
Figure 1-2. Typical VDA6800+ Front Module
