26 VCA / VDA / VEA6800+ Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 3: Specifications
Inputs
Table 3-1. VCA6800+ Input Specifications
Item Specification
Number of inputs 1
Video input level 1Vp-p nominal
Maximum input level 2.5 Vp-p centered at 0 V
Input impedance 75Ω looping or internal terminating
selectable
Coupling AC- and DC-selectable
Input return loss > 45 dB to 5 MHz
> 40 dB to 10 MHz
CMRR > 65 dB to 1 kHz
Table 3-2. VDA6800+ Input Specifications
Item Specification
Number of inputs 1
Video input level 1Vp-p nominal
Maximum input level 2.5 Vp-p centered at 0 V
Input impedance 75Ω looping or internal terminating
selectable
Coupling DC
Input return loss > 45 dB to 5 MHz
> 40 dB to 10 MHz
CMRR > 65 dB to 1 kHz
