Hatz M Series User Manual

3-4L43C, 3-4M43, 3-4M43Z Technical data
HATZ
21Manual
4 Technical data
4.1 Engine information and filling quantities
Type 3L43C, 3M43, 3M43Z 4L43C, 4M43, 4M43Z
Type Air cooled four stroke diesel engine
Combustion system Direct injection
Number of cylinders 3 4
Bore/stroke mm 102 / 105 102 / 105
Displacement cm
3
2574 3432
Engine oil pressure
at oil temperature of
100 ± 20°C
Min. 0.6 bar at 950 rpm
Engine oil consumption
(after running-in period)
Max. 1% of fuel consumption, pertaining to full load
Sense of rotation When viewing flywheel: left
Tappet clearance at
10 - 30 °C inlet/outlet mm 0.10 0.10
Net weight
.M43
.M43Z
.L43C
approx.
kg
328
335
383
393
408
453
Max. perm. inclination
during continuous opera-
tion in direction
With
oil sump
Without
oil sump
Only with
oil sump
Operating side
Air outlet side
Timing cover side
Flywheel side
30°
1)
30°
1)
25°
1)
22°
1)
25°
1)
30°
1)
25°
1)
25°
1)
25°
1)
30°
1)
15°
1)
18°
1)
Battery capacity Min/max 12V – 88/143Ah/24V – 55/110Ah
1)
Exceeding these limit values causes engine damage.
