3-4L43C, 3-4M43, 3-4M43Z Operation and use
HATZ
35Manual
Procedure
Step Activity
1 Fill with fuel if necessary.
2 Place a suitable container under the filter (2) to collect emerging
fuel.
3 Open the bleed screw (1) by approx. one turn.
4 Squeeze and release the rubber ball (3) repeatedly until fuel
emerges from the bleed screw (1).
5 Close the bleed screw (1) and then activate the rubber ball two
more times.
7.4 Starting the engine
The standard equipment of the engine is an electric start mechanism.
If possible, separate the engine from the machine being driven by uncou-
pling it. Always switch the machine into idle mode.
Safety notes
DANGER
Danger to life from inhaling exhaust gases.
Toxic engine exhaust gases can lead to loss of consciousness
and even death in closed-off and poorly ventilated rooms.
Never operate the machine in closed-off or poorly ventilated
rooms.
Do not breathe in the exhaust gases.
CAUTION
Danger of engine damage from the use of starting fluid.
Engine damage from the use of starting fluid can lead to un-
controlled ignition.
Engine damage from uncontrolled ignition.
Never use starting fluid.
NOTICE
See also starting instructions in the documentation for the com-
plete machine.
