Engine design 3-4L43C, 3-4M43, 3-4M43Z
26
HATZ
Manual
5 Engine design
Engine 3-4L43C (sealed version - Silent Pack)
Pos. Designation
1 Air intake duct for capsule
2 Intake opening for combustion air and cooling air
