3-4L43C, 3-4M43, 3-4M43Z Engine design
HATZ
27Manual
Pos. Designation
3 Fuel filter
4 Powerbox
5 Retractable lifting eye, max. load 5000 N
6 Central connector for electrical equipment
7 Control unit for exhaust emission after-treatment
8 Oil filling opening and dipstick
9 Engine type plate
10 Oil filter
11 Cover plate on operating side
12 Fuel return line
13 Manual fuel pump
14 Fuel feed line with fuel prefilter
15 Battery connections
16 Engine mount
17 Oil drain screw
18 Drain screw on the water separator
19 Capsule hood
20 Air outlet duct for cooling air
21 Catalytic converter with diesel particulate filter
22 Air guide housing cover (access to the poly v belt)
23 Exhaust pipe
24 Cover plate on air outlet side
25 Fuel evaporator (vaporizer)
