Operation and use 3-4L43C, 3-4M43, 3-4M43Z
44
HATZ
Manual
CAUTION
Danger of later engine damage.
▪ Operating the engine with an oil level below the min. mark
or above the max. mark can lead to engine damage.
▪ When checking the oil level, the engine must be horizontal
and have been switched off for a few minutes.
Overview — Checking oil level/adding oil
Pos. Designation
1 Dipstick
2 Code letter on the dipstick
Procedure — Checking oil level/adding oil
Step Activity
1 Switch off the engine and wait several minutes for the engine oil
to collect in the crankcase. Engine must be level.
2 Remove contamination on the engine in the area of the dipstick
(1).
3 Pull out the dipstick and clean it.
4 Reinsert the dipstick.
5 Pull out the dipstick and check the oil level.
6 If the oil level is close to the min. mark, add engine oil to the
max. mark.
For the specification and viscosity, see chapter 4.3 Engine oil,
page 24.
7 Reinsert the dipstick.
