Operation
14 A01681_03_X00_04 HBM: public K148
Eight-channel measuring mode (channels 1-4, channels 5-8)
1
13
14
25
Assignement
2
1
3
15
16
14
Hsg.
5
4
6
18
19
17
8
7
21
9
22
20
11
10
12
24
25
23
Hsg.
Cable
shield
Hsg. Hsg.
1/5
K148
2/6 3/7 4/8
Subchannel:
25‐pin SUB D connec
tor
Bridge excitation voltage. (-)
Bridge excitation voltage. (+)
Measurment signal (+)
Sense line (-)
Sense line (+)
Measuring signal (-)
1
2
3
4
PIN assignment, 25-pin sub‐D
connector
Fig. 5.3 :K148 connector pin assignment (CHANNELS 1-4, 5-8)
