HBM MX840B - Connection Via Firewire (IEEE 1394 B)

Connecting individual QuantumX modules
74 I3031-14.0 HBM: public Quantum
X
Notice
You can update the firmware of the modules directly via
Ethernet, or via the CX27 gateway. You must never dis
connect the data link while the update process is running.
7.2.6 Connection via FireWire (IEEE 1394b)
General information
S Baud rate of 400 MBaud (approx. 50 MByte/s)
S Asynchronous (all nodes) or isochronous (in real time)
data transmission
S Data synchronization
S Supply voltage via FireWire connection cable (max.
1.5 A)
