HBM T12 - Performance Specifications

59
T12
A1979−10.0 en HBM
Nominal (rated) torque M
nom
Nm 100 200 500
kNm 1
Temperature effect per 10 K in the nominal
(rated) temperature range
on the output signal, related to the actual value
of the signal span
%
< 0.03
on the zero signal % < 0.03
Residual ripple mV < 3
Angle of rotation
Accuracy degrees 1 (typ. 0.1)
Resolution degrees 0.01
Correction of runtime deviation between
torque LP1 and the angle of rotation for filter
frequencies
Hz
4000; 2000; 1000; 500; 200; 100
Measuring range degrees
0 to 360 (single-turn) to "1440
(multi-turn)
Performance
Measurement frequency range Hz 80 (−1 dB)
Resolution W 1
Full scale value W
P
max
+ M
nom
@ n
nom
@
p
30
[M
nom
] in Nm
[n
nom
] in rpm
Temperature effect per 10 K in the nominal
(rated) temperature range on the power signal,
related to the full scale value
%
"0.05@n/n
nom
Non-linearity including hysteresis, related to
the full scale value
%
"0.02@n/n
nom
Sensitivity tolerance (deviation of the actual
measurement signal span of the power signal
related to the full scale value)
%
"0.05
Temperature signal of the rotor
Accuracy K 1
Measurement frequency range Hz 5 (−1 dB)
Resolution K 0.1
Physical unit − C
Data rate
Meas.
values/
s
40
