HBM T12 - Stator Dimensions (100-10 kN·m, Rot. Speed)

T12
74
A1979−10.0 enHBM
16.5 Stator 100 Nm to 10 kNm with rot. speed meas. system
b
H1
H2
180
150
66
24
45
28 (28)
10
8
28
56
6.5
For rotational speed measuring system and rotational
speed measuring system with reference marker only
approx. 100
min. 43
Reserved additional
space for connected state min. 10
*)
Reserved additional space for
mounting and dismounting
approx. 20
approx. 54
Cable socket adjustable
in 4 angular positions
Accessories
Cable socket 7-pin and 8-pin
90 cable routing
Reserved additional
space for connection
cable with plug
114.3 = 4 1/2
”
UNF 1/4”
Maximum thread reach 0.4”
+0.02
”
M6
Maximum thread reach 10
+1
Dimensions without tolerances, per DIN ISO 2768−mK
Side view Y Side view X
Top view
View Z
Y
X
Z
Air gap area:
Radially = 10 mm
Axially = b
2
(see page 70)
62
Stator mid−point
*)
At 5 kNm and 10 kNm: min. 14 mm
Dimensions in mm (1 mm = 0.03937 inches)
Measuring range
Dimensions in mm (1 mm = 0.03937 inches)
(NVm) b D H1 H2
100
81 122 260 194.5
200
500
91.5 143 280 204.5
1 k
2 k
109.5 179 310 222.5
3 k
5 k 123.5 207 333 239.5
10 k 144.5 249 369 263.5
