HBM T12 - Stator Dimensions (2-10 kN·m, Prot. Contact)

T12
78
A1979−10.0 enHBM
16.9 Stator 2 kNm to 10 kNm with prot. against contact
Connection holes Z
View A
A
Z
Z
Z
Z
(Housing)
View without protection against contact half
View without cover plate
Protection against
contact
Connecting hole with countersinking
(Cover plate)
(Cover plate)
d
1
b
2
b
3
b
3
b
1
b
4
b
2
b
5
H1
H2
H3
H4 H5
d
2
d
3
d
4
b
2
b
1
b
8
11
6.6
(6.6)
(11)
b
6
b
7
H6
d
5
H7
b
9
(Locking screw)
Measuring range
Dimensions in mm (1 mm = 0.03937 inches)
b
1
b
2
b
3
b
4
b
5
b
6
b
7
b
8
b
9
H
1
H
2
H
3
H
4
H
6
H
5
H
7
2 kNm/3 kNm 58 56 1 2 4 12 32 43 97.5 116 222.5 353 121.5 107 120.5 117.3
5 kNm 80 78 1 2 2 12 32 65 99 133 239.5 384 138.5 120 134.5 134.3
10 kNm 88 86 1 2 2 12 32 73 99 157 263.5 429 162.5 145 155.5 158.3
Measuring range Dimensions in mm (1 mm = 0.03937 inches)
d
1
d
2
d
3
d
4
d
5
2 kNm/3 kNm 175 259
+2
241 232 223
−2
5 kNm 203 289
+2
269 260 249
−2
10 kNm 245 331
+2
311 302 291
−2
