73

T12

A1979−10.0 en HBM

16.4 Stator 100 Nm to 200 Nm with rot. speed meas. system

For rotational speed

measuring system and

rotational speed

measuring system with

reference marker only

84

View A

Dimensions in mm (1 mm = 0.03937 inches)

Table of Contents

Default Chapter3
- Table of Contents3
Safety Instructions5
1 Markings Used9
- Symbols on the Transducer and / or Stator9
- The Markings Used in this Document10
2 Scope of Supply11
3 Operation11
4 Application12
5 Signal Flow13
6 Structure and Mode of Operation14
7 Mechanical Installation16
- Important Precautions During Installation16
- Conditions on Site17
- Mounting Position17
- Installing the Slotted Disc (Rotational Speed Measuring System Only)18
- Installing the Rotor19
- Fitting the Protection against Contact (Option)21
- Installing the Stator27
- Optical Rotational Speed/Angle of Rotation Measuring System (Option)33
  - Axial Alignment33
  - Radial Alignment34
8 LED Status Display36
- Measuring Mode Operation36
- Rotor Clearance Setting Mode Operation36
- Rotational Speed Measuring System Setting Mode Operation36
9 Electrical Connection37
- General Information37
- Shielding Design39
- Connector Pin Assignment39
- Supply Voltage43
10 Shunt Signal45
11 Load-Carrying Capacity46
12 Teds47
13 Maintenance54
14 Waste Disposal and Environmental Protection55
15 Specifications56
- Nominal (Rated) Torque 100 NM to 1 KnM56
- Nominal (Rated) Torque 2 KnM to 10 KnM63
16 Dimensions70
- Rotor 100 NM to 200 NM70
- Rotor 500 NM to 10 KnM71
- Stator 100 NM to 200 NM with Rot.speed Meas. System72
- Stator 100 NM to 200 NM with Rot. Speed Meas. System73
- Stator 100 NM to 10 KnM with Rot. Speed Meas. System74
- Stator 100 NM to 200 NM with Prot. against Contact75
- Stator 100 NM to 200 NM with Prot. against Contact76
- Stator 500 NM to 1 KnM with Prot. against Contact77
- Stator 2 KnM to 10 KnM with Prot. against Contact78
  - Protection against Contact Plates 100 NM to 200 NM79
  - Protection against Contact Plates 500 NM to 10 KnM79
- Mounting Dimensions80
17 Supplementary Technical Information81
18 Condition at the Time of Delivery82
19 Ordering Numbers87
20 Accessories88
