Structure and mode of operation
18 A3452-10.0 T40B
Antenna segments
Rotor
Connector
plugs
Stator housing
Type plate
Connector plugs
Sensor head for
measuring
rotational speed
Magnetic ring for rotational
speed measurement
Sensor head for the
reference signal
Fig. 4.3 Mechanical construction with rotational speed
measuring system and sensor for the reference
signal (zero index), Option 7, Code S
