Structure and mode of operation
20 A3452-10.0 T40B
Information
Mechanical construction with rotational speed measuring
System is the same as in Fig. 4.2 with additional shield
ing plate of antenna ring see Fig. 4.4.
Important
The use of the shielding plates are important to ensure
compliance with FCCregulations. If the shielding plates
has to be removed for any purpose (e.g. in-stallation or
maintenance), they must be replaced in the original posi
tion be-fore the product is used.
