HBM T40B - Page 70

Specifications
68 A3452-10.0 T40B
Nominal (rated) torque M
nom
105321kNVm
Nominal (rated) sensitivity
(span between torque = zero
and nominal (rated) torque)
Frequency output 10kHz /
60kHz / 240kHz
kHz 5/30/120
Voltage output V 10
Sensitivity tolerance
(deviation of the actual output
quantity at M
nom
from the
nominal (rated) sensitivity)
Frequency output % "0.1
Voltage output % "0.1
Output signal at torque=zero
Frequency output kHz 10/60/240
Voltage output V 0
Nominal (rated) output signal
Frequency output
with positive nominal
(rated) torque
kHz 15
20)
/ 90
21)
/ 360
22)
(5 V symmetrical
23)
)
with negative nominal
(rated) torque
kHz 5
20)
/ 30
21)
/ 120
22)
(5 V symmetrical
4)
)
Voltage output
with positive nominal
(rated) torque
V +10
with negative nominal
(rated) torque
V 10
Load resistance
Frequency output kΩ ≥ 2
Voltage output kΩ ≥ 10
Long‐term drift over 48 h at
reference temperature
Frequency output % t"0.03
