Specifications
T40B A3452-10.0 69
Nominal (rated) torque M
nom
105321kNVm
Voltage output % t"0.03
Measurement frequency
range, -3 dB
kHz 1
20)
/ 3
21)
/ 6
22
)
Group delay μs t400
20)
/ t220
21)
/ t150
22
)
Residual ripple
Voltage output
24)
mV t40
Maximum modulation
range
25)
Frequency output kHz 2.5 to 17.5
20)
/ 15 to 105
21)
/
60 to 420
22)
)
Voltage output V -12 to +12
Energy supply
Nominal (rated) supply voltage
(separated extra‐low DC
voltage)
V 18 to 30
Current consumption in
measuring mode
A < 1
Current consumption in startup
mode
A < 4 (typ. 2) 50 μs
Nominal (rated) power
consumption
W < 10
Maximum cable length m 50
Shunt signal approx. 50% of M
nom
Tolerance of the shunt
signal, related to M
nom
% <"0.05
Nominal (rated) trigger voltage V 5
Trigger voltage limit V 36
Shunt signal ON V min. >2.5
Shunt signal OFF V max. <0.7
