Electrical connection
20 A2335-2.0 HBM: public VK20A
5.1.7 Electrical connection of speed/angle of
rotation output (n/ )
Strip terminal/ ter
minal
Function I/O
1)
St5 /1
Measurement signal: speed/angle of rotation 0 V;
O
/2 None -
/3 None -
/4 Measurement signal: speed/angle of rotation 5 V (+) O
/5 Measurement signal: speed/angle of rotation 5 V (-) O
/6 Measurement signal: speed/angle of rotation 5 V (-);
90° phase shifted
O
St6 /1 Measurement signal: speed/angle of rotation 5 V (+);
90° phase shifted
O
/2 None -
/3 None -
/4 None -
/5 None -
/6 None -
Tab. 5.6 Connector pin assignment
1)
O=Output; I=Input
