C 08 Order No. BA 92-20-262 Issue 01.03.08 39
8 Appendix
In the appendix, there is information of interest regarding technical data, spare part lists,
accessories, standards, etc.
8.1 Technical Data
Welding Gun Type C 08
for CD stud welding according to current standards
Welding range #4 to 5/16'', dia. 14 ga to 5/16"
(M3 to M8, dia. 2 to 8 mm)
other dimensions on request
Stud length 0.24" to 1.57" (6 to 40 mm), longer studs can
be welded with optional accessories
Stud material Mild steel, stainless steel
Stud type Any type or shape (special chucks if
required)
Spring pressure Adjustable, arresting
Welding cable 21.33' (6.5 m)
Protection class IP 20 (protect against humidity)
Workplace noise level > 90 dB (A) may occur during welding
Operational and storage conditions According to current standards
Dimension L x W x H 6.70" x 1.57" x 5.51" (170 x 40 x 140 mm)
(without cable)
Weight 1.10 lbs (0.5 kg) (without cable)
