8.2 Spare Parts
Spare part list welding gun type C 08 (92-20-262)
When ordering spare parts, please indicate order number and type of welding gun.
Pos. Quantity Order No. Description
1 1 88-10-673B Basic shell, complete
3 1 80-09-045 Cover shell
5 3 80-11-270 Screw EJOT A30x8
6 2 80-11-271 Screw EJOT A30x12
7 1 80-50-014 Micro switch
9 2 80-90-102 Screw M2 x 10
11 1 80-09-029 Trigger complete
13 1 80-08-380A Cable clamp
21 1 80-09-843B Piston contact complete
31 1 80-09-765 Pressure spring , contact
35 1 80-09-022 Axial arrest
37 1 88-10-678A Adjustment piece spring force, complete
39 1 80-11-272 Sticker, spring force
41 1 88-10-879 End ring
49 1 80-70-139 Connecting line, complete
51 1 80-10-019 Antikink bushing
53 11 80-10-021 Cable clamp
55 1 80-50-059 Cable connector
57 1 80-50-013 Control cable connector
63 1 80-09-021B Connection cable
65 1 80-90-153 Nut M 4
67 3 80-90-164 Washer 4 mm
69 1 80-90-108 Screw M4 x 12
70 1 80-90-110 Screw M4 x 8
75 2 80-11-476 Sticker
79 1 80-20-013 Bellows
81 1 80-40-040 Retaining nut
83 1 80-10-027 O-ring
