for Description Order No.
------------------------------------------------------------------------------------------------------------------------------------------------------------------
Accurate positioning Centering device complete PZV2
in welding templates with cylinder pin, centering pot
and chuck extension
Ø 20 mm 92-40-111
Ø 26 mm 92-40-117
Ø 30 mm 92-40-119
PZV2 Centering tube
Ø 20 mm 80-40-082
Ø 26 mm 80-40-086
Ø 30 mm 80-40-083
PZV2 Centering pot (to adjust)
Ø 20 mm 80-40-092
Ø 26 mm 80-40-096
Ø 30 mm 80-40-093
PZV2 Pin 10 x 70 (to adjust) 80-10-092
PZV2 Chuck extension 80-40-081
