11 Connection
Only loosely made connections will result in damage to the plug con-
nectors.
Therefore always check that the plug connector is rmly inserted.
This prevents a poor contact and hence overheating of the plug connectors.
Connect the ground clamps
Remove rust, paint and dirt from the points on the workpie-
ce to which you wish to connect the ground clamps.
Attach the ground clamps to the workpiece as tightly as
possible.
Pay attention to a good contact and symmetrical connec-
tion.
The welding point should be in the middle between the two ground
clamps.
