About this Document
Icons and symbols / Signaux et symboles
Mandatory signs
Icon Explanation Icon Explanation
Observe information Use eye protection
Follow additional
information
Use hand protection
Use protective clothing Use foot protection
Pull the power plug after
use.
Pull the power plug prior
to opening the housing.
Use ear protectors
Other icons and symbols
Icon Explanation
➜
You must do something here
✓
This must be met prior to following any operating instructions
▪
▪
▪
Something is listed here
1.
2.
3.
Operating instructions must be performed in the listed sequence.
Deviations from the speci ed sequence may result in damages of the
equipment and in accidents.
a.
b.
c.
List of variants
Images
Item numbers in the images in the text are conveyed in parentheses. If no image
number is listed, the item number refers to the image/graphic directly above the text.
If the reference is made to another image/graphic, the image number is speci ed accord-
ingly, i.e. (Fig. 4-1 (11))).
