Heidolph Hei-VAP Value - Install the Vapor Tube

Set-up and Start-up
Hei-VAP Value, Hei-VAP Advantage 21
EN
WARNING
Risk of injuries due to retracting or entrapment!
Risk of injury.
A risk of entanglement exists on the movable parts of the unit.
 Wear suitable protective clothing for activities on the rotary
evaporator with goggles and gloves.
Attach the support rod (1) to the drive unit (2) via a fastening screw (3).
4.5.2 Install the vapor tube
The evaporator flask and the vapor tube are connected with the condenser and the rota-
tion of the evaporator flask is made possible by the drive unit.
WARNING
Glass breakage!
Serious injuries from shattering and breaking glass.
 Check glass devices for damages (stars, breaks, etc.).
 Only use perfect glass devices and replace all damaged
glassware as soon as possible.
 Work carefully.
CAUTION
Unintentionally rotating drive!
Injuries to hands.
 Verify that the rotation is displayed.
WARNING
Risk of injuries due to retracting or entrapment!
Risk of injury.
A risk of entanglement exists on the movable parts of the unit.
 Wear suitable protective clothing for activities on the rotary
evaporator with goggles and gloves.
Install the vapor
tube
