Set-up and Start-up
40 Hei-VAP Value, Hei-VAP Advantage
4.9 Operating the control panel
Figure 4–31: Control panel (for Hei-VAP Precision)
The control panel can be removed from the base unit.
The 1.3 m connecting cable between the control panel and the
base unit can be adjusted to the optimal length by a cable run and
reel.
The control panel can therefore be placed on a shelf and offers a
slight inclination for a view from above.
The control panel can be attached to a wall by pre-fabricated
holes or by an enclosed Velcro-connection.
1. Grasp the control panel on the left and pull it forward from the base unit.
Avoid pressure on the LCD screen.
