Heinzmann KRONOS 20 - Wiring Diagrams; Wiring Diagram for KRONOS 20 with Open Loop

6 Electric Connection
32 KRONOS 20
6.1 Wiring Diagrams
6.1.1 Wiring Diagram for KRONOS 20 with open Loop
1 2 3 4 5 6 7 8 9 1011121314151617 18 19 20 21
12/24 V
2
1
5
6
KRONOS 20
E-LES
Electronically
controlled MAS
Battery
Fuse
6 A
Governor
on
Control Unit
Engine Stop
Common Alarm
3
4
7
3
2
4
1
Boost Pressure Sensor
Temperature Sensor
A
B
Magnetic Pickup IA ..
542
3
T x D
R x D
24V
0V
Connection to
Programmer
or PC
1
SUB-D plug 9-pole
T
HL
Figure 16: Wiring Diagram for KRONOS 20 with open Loop
