Heinzmann KRONOS 20 User Manual

5 Gas Valves E-LES
26 KRONOS 20
5.3 Dimensional Drawings
60
1
2
3
4
5
6
7
GND
+UB
Ph1
Ph2
M5 M5
M5
M5
48
32
138
48
48
94
32
48
60
42,5
10
DO NOT DISCONNECT WHILE CIRCUIT
IS LIVE UNLESS AREA IS KNOWN TO
BE NON-HAZARDOUS!
WARNING - EXPLOSION HAZARD
BEFORE REMOVING THE COVER,
SWITCH OFF THE POWER SUPPLY
AND WAIT AT MINIMUM 5 SECONDS
TO DISCHARGE THE ENERGY OF
THE CAPACITIES!
Figure 10: Dimensional Drawing E-LES 30
