6 Electric Connection
36 KRONOS 20
6.3 Enclosed Cables
The following cables will be provided by HEINZMANN in the required length.
6.3.1 Cable W2 to Gas Valve E-LES
1
2
3
4
5
6
7
GND
+UB
Ph1
Ph2
Length on request (max. 15 m)
Housing
2
1
21
20 1
2
4
5
Ground
+UB
Phase 2
Phase 1
Screen
brown
green
yellow
white
Terminal Plug Pin Function Colour
Terminal Assignment of Cable
Figure 20: Cable W2
