6 Electric Connection

38 KRONOS 20

6.3.3 Cable W4 to Speed Pickup IA…

Length on request (max. 15 m)

Housing

12 A

B Signal

Ground

Screen

Terminal Plug Pin Function No.

Terminal Assignment of Cable

Figure 22: Cable W4
