6 Electric Connection
KRONOS 20 37
6.3.2 Cable W3 to Pressure / Temperature Sensor P/T-S-01
Length on request (max. 15 m)
Housing
16
6
4
15 1
2
3
4
Ground
NTC Signal
+ 5V
Pressure Signal
Screen
brown
white
green
yellow
Terminal Plug Pin Function Colour
Terminal Assignment of Cable
Figure 21: Cable W3
