5 Gas Valves E-LES

KRONOS 20 27

GND

138

114

71,5

46,5

62,532,5

DIN 2999-R2

48,5

221

58,5

62,5

+UB

Ph1

Ph2

DIN 2999-Rp2

Figure 11: Dimensional Drawing E-LES 50
