5 Gas Valves E-LES
28 KRONOS 20
1
2
3
4
5
6
7
GND
+UB
Ph1
Ph2
80
200
336
105
125
130
76
226
Connection flange fitting to
welding-neck flange according
to DIN 2633 PN 16 DN 80
Figure 12: Dimensional Drawing E-LES 80
