HELIX P SIX DSP MK2

25
HELIX Extension Card slot (HEC slot)
It is possible to extend the functionality of the HELIX
P SIX DSP MK2 by inserting an optional HELIX
Extension Card (HEC) - for example a Bluetooth
®
Audio Streaming module, an additional optical digi-
tal input or an optical digital output.
To install a HELIX Extension Card it is necessary to
remove the bottom plate and one side panel of the
P SIX DSP MK2 and replace it by the new side pan-
el that comes with the HEC. Any further mounting
information will be found in the instruction manual
of the respective HELIX Extension Card.
HELIX Extension
Card slot
