4－
3
LUBRICANT SYSTEM
Operation / Parts Name Q’ty Remarks
1
2
3
4
5
Disassembly
Fuel tube
Fuel connection tube
Pan phillips bolt
Control cable
Oil pump
1
1
2
1
1
4WARNING:
Clogging the tube to avoid fuel flow out.
• Remove from both side of oil pump.
• Remove from oil pump.
Assembly
5→1
• Assembly with sequence in reverse
of disassembly.
4WARNING:
−Smear oil to new O ring ,before install
the oil pump into crank case.
−The oil pump must correctly installed
into crank case.
4WARNING:
−Don’t loosen adjusted screw on control
cable.
−Adjust the cable if it’s loose.
To Next Page
