HER CHEE ATV-50 - Front Brake Disassembly

11－
4
FRONT WHEEL/FRONT SUSPENSION/ FRONT BRAKE
Disassembly of Front Brake
Operation / Parts name Q’ty Remarks
1
2
3
4
5
6
7
Disassembly brake plate
Handle bar
Release adjustment screws
Release front (left or right) wheel
Ass’y
Strain spring
Front brake shoe Comp.
Release brake cables
Front brake panels
1
2
2
2
2
2
2
Assembly
7→1
z Assem
b
ling with sequence in
reverse of disassembly.
