HER CHEE ATV-50 - Crank Case Assembly and Disassembly

10－
2
Crank Case / Crank Shaft
Assembly / Disassembly of Crank Case
Operation / Parts name Q’ty Remark
1
2
3
4
5
6
7
8
9
10
11
12
13
Disassembly
Hex socket bolt
Right crank shaft case
Dowel pin
Fix shaft of crank shaft case
External circle clip
Crank shaft
Radial ball bearing (Right)
Radial ball bearing (Left)
Hex socket bolt
Oil seal bracket
Right oil seal
Left oil seal
Radial ball bearing
6
1
2
1
2
1
2
1
1
1
1
1
2
Assembly
13→1
