5－
3
FUEL SYSTEM
Operation / Parts Name Q’ty Remarks
11
10
9
8
7
6
5
4
3
2
1
Assembly
Adjusted screw
Clamp
Needle nozzle
Washer
Sealing set of guide wire
Throttle cover
Washer
Throttle valve spring
Throttle cable
Throttle valve
Pan phillips bolt
1
1
1
1
1
1
1
1
1
1
1
＊WARNING:
Assembly of needle nozzle.
Assembly of throttle valve.
Assembly of throttle cable.
Aim the ditch of throttle valve to chamber,
then install throttle valve into
carburetor.
Lock the throttle cover.
