5－
6
FUEL SYSTEM
Operation / Parts Name Q’ty Remarks
1
2
3
Disassembly
Plunger starter
Pan phillips bolt
Auto-side plunger
Oil ring
2
1
1
4
5
6
7
8
9
10
Float Chamber
Pan phillips bolt
Drain screw
Over flow tube
Pan phillips bolt
Float pin
Float
Needle valve
4
1
1
1
1
1
1
11
12
13
14
15
16
Carburetor Ass’y
Throttle screw set
Air adjust screw set
Float chamber seal
Pilot jet
Main jet base
Main jet
1
1
1
1
1
＊WARNING: Must confirm rotation
before disassembling.
Not locking too much, avoid to
hurt seat face.
12
Assembly
16→1
Air adjust screw set
‧Operating with sequence in reverse of
Disassembling.
＊WARNING: use high pressure air clean
each way of carburetor.
＊WARNING: must adjust air screw
when changing air screw and
carburetor ass’y.
To Next Page
