Heraeus UT 20 P - Fixed Program Segments; Compilation of a Fixed Program

• Fixed program segments:
Program segment" P 1. n " (n = -, 0... 9):
Assigning a parameter (0 ... 9) from the database causes the unit to switch on heating and ventilation
on expiry of a preset period.
Selectable parameters In this program segment:
PI- PL 0
PI. I PI. 2 PI. 3 PI. 4
PI. 5
PI. 6 PI. 7 PI. 8 PI. 9
Off
2h 4h
6h
8h
10h 12h 16 h 20 h 24 h 72 h
Program segment" P 2. n " (n «-, 0 ... 9):
Assigning a parameter (0 ... 9) causes the unit to heat up to the preset operating temperature at a
specific rate of temperature change per hour.'
1
Selectable parameters In this program segment:
P2.- P2. 0
P2.1
P2. 2
P2.3
P2. 4 P2. 5 P2.6
P2. 7
P2. 8 P2. 9
off
10*C/h 20'C/h 30"C/h 40'C/h 50'C/h
60*C/h 80'C/h
100'C/h 120*C/h
200'C/h
Program segment" P 3. n " (n • -, 0... 9):
Assigning a parameter (0... 9) causes the unK to heat up to the preset operating temperature, to
maintain this temperature for the preset period and to subsequently switch off heating and
ventilation
Selectable parameters In this program segment:
P3.-
P3.0 P3.1
P3.2
P3.3
P3.4
P3.5 P3.8 P3.7
P3. 8 P3. 9
off 15 min.
30 mln. 1h
1.5 h
2h
4h
6h
8h 12 h 24 h
Program segment" P 4. n " (n «-, 0 .*9):, .
Assigning a parameter (0... 9) causes the unit to cool down from the previously reached Inside
temperature at a specific rate of temperature Change and to subsequently switch off heating and
ventilation.
11
•*: ;
Selectable parameters In this program segment:
P4.-
P4.0 P4.1 P4.2 J»4
!
/3' P4.4 P4.5 P 4.6 P 4.7 P4.8 P 4.9
off 1'C/h
2*C/h
5'C/h 10*C/h 20"C/h 30"C/h 40'C/h 50'C/h 60"C/h 80'C/h
1) KOORDng lo nvxM »nd load
• Compilation of a fixed program
After activating the added-feature function, the sequence is compiled by marking the required
program segments.
Example: Fixed program comprising P I. 2; P 2. -; P 3.7; P 4.4 and P. o n :
